  • America UL Rubber Cords SJ SJO SJOO SJOW SJOOW

    America UL Rubber Cords SJ SJO SJOO SJOW SJOOW


    Rubber Cable UL cUL certifications for North America as Unite states and Canada.

  • specifications

  • Type Conductor Insulation Thickness Jacket Thickness Overall Diameter Min.Cross-sectional area of Conductor
    Size No./mm [mm] [mm] [mm] [mm2]

    SJ 18AWG/2C 41/0.160 0.76 0.76 7.30±0.15 0.798
    SJ0 16AWG/2C 65/0.160 0.76 7.90±0.15 1.27
    SJ00 14AWG/2C 41/0.254 0.76 8.70±0.15 2.02
    SJ0W 18AWG/3C 41/0.160 0.76 7.80±0.15 0.798
    SJ00W 16AWG/3C 65/0.160 0.76 8.30±0.15 1.27
      14AWG/3C 41/0.254 0.76 9.50±0.15 2.02
      18AWG/4C 41/0.160 0.76 8.50±0.15 0.798
      16AWG/4C 65/0.160 0.76 9.20±0.15 1.27
      14AWG/4C 41/0.254 0.76 10.2±0.15 2.02
      18AWG/5C 41/0.160 0.76 9.30±0.15 0.798
      16AWG/5C 65/0.160 0.76 10.1±0.15 1.27
      14AWG/5C 41/0.254 0.76 11.2±0.20 2.02
      12AWG/2C 65/0.254 1.14 10.4±0.20 5.43
      12AWG/3C 65/0.254 1.14 10.9±0.20 5.43
      12AWG/4C 65/0.254 1.14 12.0±0.20 5.43
      12AWG/5C 65/0.254 1.14 13.2±0.20 5.43

    Other Termination Options:


    Click Here

    Item NO Number Voltage Number of maximum current Number of conductors Jacket Type Jacket Color Standard
    SJ SJO SJOW SJOO SJOOW 300/600V 12-50A 2-5 PVC,Rubber Any as Requested CSA CAN/CSA-22.2 No.21-95
    End of treatment MOQ Payment Transportation Delivery period Packing Wiring Standard
    Bare 50000m T/T By air or sea 15 days Export cartons as bellow
